• Country
• Germany

• Manufacturer / Brand
• SABA; Villingen

• Year
• 1928–1930

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 6763

• • Brand: Schwer & Söhne, GmbH

• Number of Tubes
• 4

• Valves / Tubes
• RE074n RE084 RE084 RE134

• Main principle
• TRF with regeneration; 1 Special; 2 AF stage(s)

• Tuned circuits
• 2 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage and/or dry batteries / 200 + 120 + 50 + 4 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: Oekonom 2300 [Metall] - SABA; Villingen

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Dimensions (WHD)
• 400 x 200 x 210 mm / 15.7 x 7.9 x 8.3 inch

• Notes
• 200-2300 m

• Price in first year of sale
• 160.00 RM +

• Source of data
• Arlt's grosser Radiokatalog 1930 / Radiokatalog Band 1, Ernst Erb

• Circuit diagram reference
• Röhren in FS-Bestückungstabellen

• Mentioned in
• Saba-Diplomarbeit
