Multimeter N-501

Multimeter N-501; Sanwa Electric (ID = 233918) Equipment Multimeter N-501; Sanwa Electric (ID = 233919) Equipment
Multimeter N-501; Sanwa Electric (ID = 1356156) Equipment Multimeter N-501; Sanwa Electric (ID = 1356157) Equipment
Multimeter N-501; Sanwa Electric (ID = 1356574) Equipment
Use red slider bar for more.
Multimeter N-501; Sanwa Electric (ID = 233918) Equipment
Sanwa Electric: Multimeter N-501 [Equipment] ID = 233918 535x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Multimeter N-501, Sanwa Electric Instrument Co., Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Sanwa Electric Instrument Co., Ltd.; Tokyo
Year: 1972 Type: Service- or Lab Equipment
schematic requested
Wave bands - without
Details
Power type and voltage Dry Batteries / 9 & 1,5 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Multimeter N-501 - Sanwa Electric Instrument Co.,
Material Various materials
Shape Miscellaneous shapes - described under notes.
Dimensions (WHD) 190 x 123 x 92 mm / 7.5 x 4.8 x 3.6 inch
Notes Passiv supersensitive analog multimeter, 2 µA full scale, 5 Ge-Diodes, Polarity switch, Measurement Ranges: DCV: 60 mV, 300 mV, 1,2 V, 3 V, 12 V, 30 V, 120 V, 300 V, 1200 V (500 kOhm/V, 50 kOhm/V 120 V and up); ACV: 3 V, 12 V, 30 V, 120 V, 300 V, 1200 V (1 MOhm fix); DCA: 0,3 µA to 300 mA; ACA and DCA: 1,2 and 12 A; Ohms: 500 to 50 M.
Wooden case flank boards, 4-mm-jacks.
