Portable Radio RP-8880 UM (=Europe Version)

Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 200869) Radio

Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 200870) Radio

Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 201253) Radio

Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 201254) Radio

Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 201256) Radio

Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 201257) Radio

Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 85545) Radio

Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 201255) Radio

Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 1262415) Radio

Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 1262416) Radio
Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 83011) Radio Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 450320) Radio
Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 450318) Radio Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 450316) Radio
Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 450317) Radio Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 450319) Radio
Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 450321) Radio Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 450352) Radio
Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 450625) Radio Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 736606) Radio
Use red slider bar for more.
Portable Radio RP-8880 UM; Sanyo Electric Co. (ID = 83011) Radio
Sanyo Electric Co.: Portable Radio RP-8880 UM [Radio] ID = 83011 933x527
Select picture or schematic to display from thumbnails on the right and click for download.
For model Portable Radio RP-8880 UM (=Europe Version), Sanyo Electric Co. Ltd.; Moriguchi (Osaka)

Country:  Japan
Manufacturer / Brand:  Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
Year: 1978 ? Type: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Principle Superhet, double/triple conversion; ZF/IF 460/10700 kHz
Wave bands Broadcast, Long Wave, more than 2 x SW plus FM.
Details
Power type and voltage Line / Batteries (any type) / 120; 200; 220; 240/ 8 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Portable Radio RP-8880 UM - Sanyo Electric Co. Ltd.;
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (usable without mains)
Dimensions (WHD) 475 x 243 x 142 mm / 18.7 x 9.6 x 5.6 inch
Notes Sanyo Portable Radio RP-8880 UM (Suffix UM = Europe Version);
Coverage:
CCIR FM: 87.5 - 108 MHz,
LW: 150 - 405 kHz,
MW: 510 - 1.605 kHz,
MB: 1.6 - 2.3 MHz,
SW1: 2.3 - 5.95 MHz,
SW2: 5.95 - 6.2 MHz,
SW3: 6.2 - 10.0 MHz,
SW4: 11.7 - 20.0 MHz,
SW5: 20.0 - 30.0 MHz,
two telescopic rods, turnable ferrite bar on top, signal meter, crystal frequency marker and analog readout, built-in BFO, ext. power jack: 12 VDC.
Net weight (2.2 lb = 1 kg) 4.5 kg / 9 lb 14.6 oz (9.912 lb)
Collectors' prices
External source of data R. Lichte

Model page created by Martin Bösch. See "Data change" for further contributors.

All listed radios etc. from Sanyo Electric Co. Ltd.; Moriguchi (Osaka)
Here you find 749 models, 605 with images and 166 with schematics.




Forum contributions about this model
Sanyo Electric Co.: Portable Radio RP-8880 UM
Threads: 1 | Posts: 3
Hits: 4912     Replies: 2
sanyo: RP-8880;
Mario Bermejo
23.May.07
  1 Dear Friends:

A friend broght me this radio to repair. The radio is working ok on MW but the FM is receiving only one station, so I think the FM oscilator is probably not working. I checked the documents attached to the model and the service manual only has page number 1. I was wondering if anyone has the complete document? I am confident I can fix it if I have the service manual.

Thanks

Mario

Henning Oelkers
23.May.07
  2

Hi, Mario,

i checked the Manuals, and i was able to see 9 different parts of the schematics. You need to click "more schematics" and then a window schould open, with the list of all schematics.

Maybe You just need to try again, or check, if this window is behind other windows. Hope this helps,

best Regards,

Henning, from Berlin, Germany

Mario Bermejo
24.May.07
  3 Thank you Henning, I downloaded all the parts which gives you the complete schematic, but then there is a file called serv1.pdf which contains only the first page of the service manual. That is what I need: the complete service manual. No big deal as I have been studying the schematic and think I can go by without it but just in case.

These service manuals often contain information on how to test the oscilators and how to re-align the radio if a repair is needed.

Thanks again.

Mario

Sanyo Electric Co.: Portable Radio RP-8880 UM
End of forum contributions about this model


rmXorg
