• Year
  • 1951 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 288948

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 480 kHz
  • Wave bands
  • Broadcast, Long Wave and more than two Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 110-250 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Romance 51 - Schneider Frères, Radio-
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 550 x 355 x 275 mm / 21.7 x 14 x 10.8 inch
  • Notes
  • 5 gammes d'ondes dont 3 x OC. Bloc R215.

    Voir aussi modèle Romance avec 6BA6 et EM34.

  • Net weight (2.2 lb = 1 kg)
  • 13.5 kg / 29 lb 11.8 oz (29.736 lb)
