Oscilloscope 4D10a

Oscilloscope 4D10a; Scopex Instruments; (ID = 1450134) Equipment

Oscilloscope 4D10a; Scopex Instruments; (ID = 1450136) Equipment

Oscilloscope 4D10a; Scopex Instruments; (ID = 1450137) Equipment

Oscilloscope 4D10a; Scopex Instruments; (ID = 1450138) Equipment

Oscilloscope 4D10a; Scopex Instruments; (ID = 1450140) Equipment
Oscilloscope 4D10a; Scopex Instruments; (ID = 858737) Equipment Oscilloscope 4D10a; Scopex Instruments; (ID = 1337882) Equipment
Use red slider bar for more.
Oscilloscope 4D10a; Scopex Instruments; (ID = 858737) Equipment
Scopex Instruments;: Oscilloscope 4D10a [Equipment] ID = 858737 669x486
Select picture or schematic to display from thumbnails on the right and click for download.
For model Oscilloscope 4D10a, Scopex Instruments; Letchworth, Herts

Country:  Great Britain (UK)
Manufacturer / Brand:  Scopex Instruments; Letchworth, Herts
Year: 1978 ?? Type: Service- or Lab Equipment
Valves / Tubes 1:
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Oscilloscope 4D10a - Scopex Instruments; Letchworth
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 310 x 310 x 160 mm / 12.2 x 12.2 x 6.3 inch
Notes Y-bandwidth 10 MHz.
Net weight (2.2 lb = 1 kg) 5.6 kg / 12 lb 5.4 oz (12.335 lb)
Literature/Schematics (1) (A) Elektronik Report Heft 5, Mai 1978, S. 55 Werbeschaltung

Model page created by Dirson Willig. See "Data change" for further contributors.
