Silvertone 7108 Ch= 101.648

Silvertone 7108 Ch= 101.648; Sears, Roebuck & Co. (ID = 667214) Radio

Silvertone 7108 Ch= 101.648; Sears, Roebuck & Co. (ID = 667215) Radio
Silvertone 7108 Ch= 101.648; Sears, Roebuck & Co. (ID = 894506) Radio Silvertone 7108 Ch= 101.648; Sears, Roebuck & Co. (ID = 894508) Radio
Silvertone 7108 Ch= 101.648; Sears, Roebuck & Co. (ID = 314304) Radio Silvertone 7108 Ch= 101.648; Sears, Roebuck & Co. (ID = 894510) Radio
Silvertone 7108 Ch= 101.648; Sears, Roebuck & Co. (ID = 314306) Radio Silvertone 7108 Ch= 101.648; Sears, Roebuck & Co. (ID = 378258) Radio
Silvertone 7108 Ch= 101.648; Sears, Roebuck & Co. (ID = 314305) Radio Silvertone 7108 Ch= 101.648; Sears, Roebuck & Co. (ID = 378259) Radio
Use red slider bar for more.
Silvertone 7108 Ch= 101.648; Sears, Roebuck & Co. (ID = 894506) Radio
Sears, Roebuck & Co.: Silvertone 7108 Ch= 101.648 [Radio] ID = 894506 933x827
Select picture or schematic to display from thumbnails on the right and click for download.
For model Silvertone 7108 Ch= 101.648, Sears, Roebuck & Co.; Chicago (IL):
Silvertone 7108 Front View

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1941 Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 1A7GT 1P5GT 1P5GT 1H5GT 1A5GT
Principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Storage and/or dry batteries / 90 & 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Silvertone 7108 Ch= 101.648 - Sears, Roebuck & Co.; Chicago
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 15 x 11.625 x 11.625 inch / 381 x 295 x 295 mm
Collectors' prices
External source of data Ernst Erb
Source of data Collector's Guide to AR4.Ed.,Bunis, tube
Circuit diagram reference Rider's Perpetual, Volume 14 = 1944 = before 1943
Literature/Schematics (1) Riders 14-49, 50
