Silvertone 1320 Ch= 109 or 109B; Sears, Roebuck & Co. (ID = 1290876) Radio
Sears, Roebuck & Co.: Silvertone 1320 Ch= 109 or 109B [Radio] ID = 1290876 600x924
Select picture or schematic to display from thumbnails on the right and click for download.
For model Silvertone 1320 Ch= 109 or 109B knobs straight, Sears, Roebuck & Co.; Chicago (IL):
By courtesy of guest Garry O'Hara, Canada. The Silvertone bomdel 1320 with the new chassis with a straight knob arrangement. Knobs he is missing! The grill clothe is not original - but probably similar!

Country:  United States of America (USA)
Manufacturer / Brand:  Sears, Roebuck & Co.; Chicago (IL)
Brand

Silvertone
Year: 1932/1933 perfect model Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 35 27 24 35 24 47 47 80
Principle Superhet with RF-stage; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 60 cycles, 110 - 120 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Silvertone 1320 Ch= 109 or 109B [knobs straight] - Sears, Roebuck & Co.; Chicago
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes

This Sears Silvertone 1320 is the superhet with the new chassis made by Sentinel Radio instead of Colonial, with the knobs in a straight line. See also the oder version with otherwise equal cabinet. See details and summaries about Sears catalogs etc.

The Sears book "Service information 1928 thru 1936" shows on page 184 the same schematic for the models 1320, 1324, 1326X, 1386, 1454, 1456, 1531 and 7004. See this special text about first Silvertone superhets. Some of these Silvertone radios (1320, 1324, 1326) were available with an earlier chassis with knobs arranged in a "v" (triangle, top down) with 3 tubes 35. Please compare with the old version Silvertone 1320 before uploading pictures.

Mentioned in Silvertone Radios, Service Inf. 1928 thru 1936 (page 184.)

Model page created by Ernst Erb. See "Data change" for further contributors.
