• Year
  • 1956 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 267920

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 18
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Ch= U74-01AA - Sentinel Radio Corp., Evanston
  • Shape
  • Chassis only or for «building in»
  • Notes
  • Sentinel Chassis U74-01AA is a 21 or 24" b/w TV with US standard VHF tuner channels 2 thru 13, and 14 thru 83 UHF. Equipped with VHF-tuner 700558-2, UHF tuner 700556-2 and picture tube 24YP4 or 21ATP4


  • Author
  • Model page created by Dirk Taekels. See "Data change" for further contributors.
