• Country
• France

• Manufacturer / Brand
• Radiola (marque)

• Year
• 1971/1972

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 272758

• • Brand: SFER

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• BF194 BF195 BF195 BC149 AC188 AC187 AA119 AA119 BA114

• Main principle
• Superheterodyne (common); ZF/IF 452 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 2.3 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: RA307T /00R - Radiola marque

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 158 x 40 x 145 mm / 6.2 x 1.6 x 5.7 inch

• Notes

• 2 gammes d'ondes PO de 525 à 1605 kHz et GO de 145 à 254 kHz. Clavier 5 touches dont 3 stations préréglées Lux, Europe 1 et France Inter.

  Haut-parleur (dans boîtier séparé), dimensions 102 x 154 mm, type AD2461SX, z = 8 ohms.

  Équivalent au Philips 22RN370 (différences mineures).

  A noter : le document de service d'origine Radiola montre le version Philips.

• Mentioned in
• -- Original-techn. papers.
