S130U

S130U; Siera; Belgien (ID = 1014952) Radio

S130U; Siera; Belgien (ID = 1924656) Radio

S130U; Siera; Belgien (ID = 1924658) Radio

S130U; Siera; Belgien (ID = 1924659) Radio

S130U; Siera; Belgien (ID = 1924660) Radio

S130U; Siera; Belgien (ID = 1924661) Radio

S130U; Siera; Belgien (ID = 1924663) Radio

S130U; Siera; Belgien (ID = 1924664) Radio

S130U; Siera; Belgien (ID = 1924665) Radio

S130U; Siera; Belgien (ID = 1924666) Radio
S130U; Siera; Belgien (ID = 1269730) Radio S130U; Siera; Belgien (ID = 472366) Radio
S130U; Siera; Belgien (ID = 472367) Radio
Use red slider bar for more.
S130U; Siera; Belgien (ID = 1269730) Radio
Siera; Belgien: S130U [Radio] ID = 1269730 930x704
Select picture or schematic to display from thumbnails on the right and click for download.
For model S130U, Siera; Belgien

Country:  Belgium
Manufacturer / Brand:  Siera; Belgien
Year: 1946 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: UCH21 UCH21 UBL21 UY1N
Main principle Super-Heterodyne (Super in general); ZF/IF 452 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110; 125; 200; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
Power out
from Radiomuseum.org Model: S130U - Siera; Belgien
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 395 x 270 x 195 mm / 15.6 x 10.6 x 7.7 inch
Notes
3 Band reception:
  • LW: 715 - 2000 m.
  • BC: 200 - 585 m.
  • SW: 16 - 51 m.
Tuning scale light bulbs type: 2 x 8095D (19V, 90mA).
Loudspeaker Philips type 9678. Connector for external loudspeaker.

This model is comparable with Mediator M207U, NSF H207U and Philips 656U.

The booklet "Siera memento of tubes and models 1932-1946" defines the I.F. at 452 kHz as apposed to the technical manual that defines it at 468 kHz. It is possible that Siera Leuven used the I.F. transformers from S130U-01.

ATTENTION: chassis connected to the mains.
Net weight (2.2 lb = 1 kg) 7 kg / 15 lb 6.7 oz (15.419 lb)
Mentioned in - - Manufacturers Literature (Siera memento of tubes and models 1932-1946)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by John Koster. See "Data change" for further contributors.
