CRF-220; Sony; Tokyo (ID = 504596) Radio
Sony; Tokyo: CRF-220 [Radio] ID = 504596 840x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model CRF-220, Sony; Tokyo

Country:  Japan
Manufacturer / Brand:  Sony; Tokyo
Year: 1972–1977 ? Type: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 42:
Principle Superhet, double/triple conversion
Wave bands Broadcast, Long Wave, more than 2 x SW plus FM.
Details
Power type and voltage Line / Batteries (any type) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 4 W (unknown quality)
from Radiomuseum.org Model: CRF-220 - Sony; Tokyo
Material Various materials
Shape Portable set > 8 inch (usable without mains)
Dimensions (WHD) 452 x 325 x 160 mm / 17.8 x 12.8 x 6.3 inch
Notes 19 shortwave bands (500 kHz segments), AM/SSB(BFO), probably Wadley loop, linear analog readout within 500 kHz SW-bands; very similar to the Sony CRF-230 but with only 1 VHF/FM-band.
Net weight (2.2 lb = 1 kg) 13.8 kg / 30 lb 6.3 oz (30.396 lb)
Price in first year of sale 1,298.00 DM
Collectors' prices
Mentioned in -- Original-techn. papers.

Model page created by Martin Bösch. See "Data change" for further contributors.
