FM/AM Walkman WM-FX105

Sony Corporation; Tokyo

  • Year
  • 1994
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 244513

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Batteries / addl. power jack / 2 × 1,5 / 3 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: FM/AM Walkman WM-FX105 - Sony Corporation; Tokyo
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 94 x 119 x 35 mm / 3.7 x 4.7 x 1.4 inch
  • Notes
  • Mega bass, AVLS, CrO2-Metal, Dolby NR, Tone Control, Ext.Power Jack DC 3 V.


  • Net weight (2.2 lb = 1 kg)
  • 0.205 kg / 0 lb 7.2 oz (0.452 lb)
  • Author
  • Model page created by Danko Tkalec. See "Data change" for further contributors.
