Tape Recorder TC-105 Solid State

Sony Corporation; Tokyo

Data

Forum

Pictures

Collections

Country
Japan

Manufacturer / Brand
Sony Corporation; Tokyo

Year
1968 ?

Category
Sound/Video Recorder and/or Player

Radiomuseum.org ID
220857

Schematics

Tape Recorder TC-105; Sony Corporation; (ID = 1262591) R-Player — Sony Corporation; Tape Recorder TC-105 (3)

Tape Recorder TC-105; Sony Corporation; (ID = 1262593) R-Player — Sony Corporation; Tape Recorder TC-105 (3)

Tape Recorder TC-105; Sony Corporation; (ID = 2762968) R-Player — Sony Corporation; Tape Recorder TC-105 (1)

Tape Recorder TC-105; Sony Corporation; (ID = 1263320) R-Player — Sony Corporation; Tape Recorder TC-105 (1)

Tape Recorder TC-105; Sony Corporation; (ID = 1263312) R-Player — Sony Corporation; Tape Recorder TC-105 (1)

Tape Recorder TC-105; Sony Corporation; (ID = 1263313) R-Player — Sony Corporation; Tape Recorder TC-105 (1)

Tape Recorder TC-105; Sony Corporation; (ID = 1263314) R-Player — Sony Corporation; Tape Recorder TC-105 (1)

Tape Recorder TC-105; Sony Corporation; (ID = 1263316) R-Player — Sony Corporation; Tape Recorder TC-105 (1)

Tape Recorder TC-105; Sony Corporation; (ID = 1263318) R-Player — Sony Corporation; Tape Recorder TC-105 (1)

Tape Recorder TC-105; Sony Corporation; (ID = 1263321) R-Player — Sony Corporation; Tape Recorder TC-105 (1)

Tape Recorder TC-105; Sony Corporation; (ID = 1263322) R-Player — Sony Corporation; Tape Recorder TC-105 (1)

Tape Recorder TC-105; Sony Corporation; (ID = 1263324) R-Player — Sony Corporation; Tape Recorder TC-105 (1)

Tape Recorder TC-105; Sony Corporation; (ID = 1263326) R-Player — Sony Corporation; Tape Recorder TC-105 (1)

Tape Recorder TC-105; Sony Corporation; (ID = 1263327) R-Player — Sony Corporation; Tape Recorder TC-105 (1)

Tape Recorder TC-105; Sony Corporation; (ID = 1641988) R-Player — Sony Corporation; Tape Recorder TC-105 (2)
Sony Manual

Tape Recorder TC-105; Sony Corporation; (ID = 1642890) R-Player — Sony Corporation; Tape Recorder TC-105 (2)
Service Manual

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
7

Semiconductors
2SD28 2SD28 2SB383 2SB383 2SC402 2SC401 2SC401

Main principle
Audio-Amplification

Wave bands
- without

Details
Tape Recorder

Power type and voltage
Alternating Current supply (AC) / 110 - 240 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

Material
Various materials

from Radiomuseum.org
Model: Tape Recorder TC-105 [Solid State] - Sony Corporation; Tokyo

Shape
Tablemodel, low profile (big size).

Dimensions (WHD)
14.8 x 7.3 x 13.4 inch / 376 x 185 x 340 mm

Notes
See also the Sony Tape Recorder TC-105 equipped with tubes instead of transistors.

Net weight (2.2 lb = 1 kg)
9 kg / 19 lb 13.2 oz (19.824 lb)

Author
Model page created by Abu Bakar. See "Data change" for further contributors.
