Sparton 135 Ch= 5A10

ID = 58518

Country: United States of America (USA)	Manufacturer/Brand: Sparks-Withington Co. (Sparton)
Year: 1949	Type: Radio or Tuner
Valves / Tubes	5: 12BE6 12BA6 12AV6 50L6GT 35W4

Principle	Super-Heterodyne (Super in general); IF-Freq. 456 kHz; 2 AF-stage(s)
Tuned circuits	6 AM circuit(s);
Wave bands	Broadcast only (MW).
Power type and voltage	AC/DC-set / 110 - 120 Volt
Loudspeaker/pwr.out	Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12.7 cm = 5 inch
from Radiomuseum.org	Model: Sparton 135 Ch= 5A10 [ ]
Material	Modern plastics (no Bakelite or Catalin)
Shape	Tablemodel, Mantle/Midget/Compact but not a Portable (Mains only).
Notes	The Sparks Model Sparton 135 is an AC/DC Operated 5 Tube AM Superheterodyne Receiver with Loop Antenna.

All listed radios etc. from Sparks-Withington Co. (Sparton)
Here you find 578 models, 134 with images and 510 with schematics.
