2224 Ch= 73B

ID = 143751

Country: United States of America (USA)	Manufacturer/Brand: Spiegel Inc. Chicago, Illinois
Year: 1939 ?	Type: Radio or Tuner
Valves / Tubes	5: 6D8G 6J7G 6L5G 6S7G 41

Principle	Super-Heterodyne (Super in general); IF-Freq. 465 kHz
Tuned circuits	6 AM circuit(s);
Wave bands	Broadcast only (MW).
Power type and voltage	Storage Battery for all / 6 Volt
Loudspeaker/pwr.out	Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
from Radiomuseum.org	Model: 2224 Ch= 73B
Notes	Farm radio. Sync. vibrator for +B. 6 or 8 inch speaker.

This model was suggested by Dirk Taekels.
