Duanett 1582 LV; SRA Svenska (ID = 1952454) Radio
SRA Svenska: Duanett 1582 LV [Radio] ID = 1952454 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Duanett 1582 LV, SRA Svenska Radioaktiebolaget; Stockholm

Country:  Sweden
Manufacturer / Brand:  SRA Svenska Radioaktiebolaget; Stockholm
Brand

Radiola
Year: 1960 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCC85 UCH81 UBF89 UCL82 UM80 UY85
Main principle Super-Heterodyne (Super in general); ZF/IF 460 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage AC/DC-set / 110; 127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Duanett 1582 LV - SRA Svenska Radioaktiebolaget;
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 390 x 200 x 170 mm / 15.4 x 7.9 x 6.7 inch

Model page created by Timo Rantasaari. See "Data change" for further contributors.



All listed radios etc. from SRA Svenska Radioaktiebolaget; Stockholm
Here you find 262 models, 141 with images and 155 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
