Radiola Kvartett 7002

Radiola Kvartett 7002; SRA Svenska (ID = 1914463) Radio

Radiola Kvartett 7002; SRA Svenska (ID = 1914464) Radio

Radiola Kvartett 7002; SRA Svenska (ID = 1914465) Radio

Radiola Kvartett 7002; SRA Svenska (ID = 1914466) Radio

Radiola Kvartett 7002; SRA Svenska (ID = 1914467) Radio

Radiola Kvartett 7002; SRA Svenska (ID = 1914468) Radio

Radiola Kvartett 7002; SRA Svenska (ID = 1914469) Radio

Radiola Kvartett 7002; SRA Svenska (ID = 1914470) Radio

Radiola Kvartett 7002; SRA Svenska (ID = 1914471) Radio

Radiola Kvartett 7002; SRA Svenska (ID = 1914472) Radio
Radiola Kvartett 7002; SRA Svenska (ID = 1914462) Radio
Use red slider bar for more.
Radiola Kvartett 7002; SRA Svenska (ID = 1914462) Radio
SRA Svenska: Radiola Kvartett 7002 [Radio] ID = 1914462 800x544
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radiola Kvartett 7002, SRA Svenska Radioaktiebolaget; Stockholm:
Aus dem Servicemanual

Country:  Sweden
Manufacturer / Brand:  SRA Svenska Radioaktiebolaget; Stockholm
Brand

Radiola
Year: 1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11: BF200 BF195 BF197 BF197 BC148 BC148 AC188 AC188 AC187 BC149 BC159
Main principle Super-Heterodyne (Super in general); ZF/IF 10850 kHz; 4 AF stage(s)
Tuned circuits 7 FM circuit(s)
Wave bands FM Broadcast Band Only
Details
Power type and voltage Batteries / addl. power jack / 4 x 1,5 / 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.8 W (unknown quality)
from Radiomuseum.org Model: Radiola Kvartett 7002 - SRA Svenska Radioaktiebolaget;
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Notes

Modell für Skandinavien; nur UKW; 3 UKW-Festsendertasten und Hand-Abstimmung; Diodenabstimmung im UKW-Mischteil; ZF = 10,85 MHz.

Mentioned in -- Original-techn. papers.

Model page created by Heiko zur Mühlen. See "Data change" for further contributors.



All listed radios etc. from SRA Svenska Radioaktiebolaget; Stockholm
Here you find 262 models, 141 with images and 155 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
