• Country
• Germany

• Manufacturer / Brand
• Bruns; Hamburg

• Year
• 1972

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 111389

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 10

• Semiconductors
• GF132 GF181 GF130 GC117 GC116 GD160 SAY15 GA101 GA109 Selengleichrichter

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Tuned circuits
• 6 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 1 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Charmant 633 - Bruns; Hamburg

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 475 x 110 x 140 mm / 18.7 x 4.3 x 5.5 inch

• Notes

• Exportmodell des Charmant 632 mit UKW bis 108 MHz, gleiches Chassis. Kunststoffgehäuse (Skonater) in Blau, Rot oder Weiß. KW nur 49-m-Band, Ferritantenne für MW und KW, Klangtaste, Lautsprecher 8 Ω.

  Halbleiter einmal je Typ gelistet.

  Hersteller: Stern-Radio Sonneberg (RFT)

• Net weight (2.2 lb = 1 kg)
• 3 kg / 6 lb 9.7 oz (6.608 lb)

• Mentioned in
• Die Geschichte der Rundfunkindustrie der DDR Band 2 1968 - 1990

• Literature/Schematics (1)
• - - Manufacturers Literature (Service- DVD vom Funkverlag B. Hein)

• Author
• Model page created by Bernd Pötzsch. See "Data change" for further contributors.
