Current Probe Amplifier AM503

Current Probe Amplifier AM503; Tektronix; Portland, (ID = 752639) Equipment

Current Probe Amplifier AM503; Tektronix; Portland, (ID = 752640) Equipment

Current Probe Amplifier AM503; Tektronix; Portland, (ID = 752641) Equipment

Current Probe Amplifier AM503; Tektronix; Portland, (ID = 752642) Equipment

Current Probe Amplifier AM503; Tektronix; Portland, (ID = 752643) Equipment

Current Probe Amplifier AM503; Tektronix; Portland, (ID = 752644) Equipment

Current Probe Amplifier AM503; Tektronix; Portland, (ID = 752645) Equipment

Current Probe Amplifier AM503; Tektronix; Portland, (ID = 752646) Equipment

Current Probe Amplifier AM503; Tektronix; Portland, (ID = 752967) Equipment
Current Probe Amplifier AM503; Tektronix; Portland, (ID = 752412) Equipment Current Probe Amplifier AM503; Tektronix; Portland, (ID = 752647) Equipment
Use red slider bar for more.
Current Probe Amplifier AM503; Tektronix; Portland, (ID = 752412) Equipment
Tektronix; Portland,: Current Probe Amplifier AM503 [Equipment] ID = 752412 714x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Current Probe Amplifier AM503, Tektronix; Portland, OR

Country:  United States of America (USA)
Manufacturer / Brand:  Tektronix; Portland, OR
Year: 1977 ? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Current Probe Amplifier AM503 - Tektronix; Portland, OR
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 2.6 x 5 x 11.7 inch / 66 x 127 x 297 mm
Notes Einschub für die TM500 Serie. AM503 ist ein Verstärker für die Stromzangen P6303 (max.100A / 15MHz) oder P6302 (max. 20A / 50MHz). Die Einstellung der Empfindlichkeit erfolgt in 12 Stufen von 1mA/div. - 50A/div. abhängig von der verwendeten Stromzange.Messung des Ausgangssignals und Auswertung der Kurvenform mit einem nachgeschalteten Oszillografen bei fest eingestellter Vertikalempfindlichkeit von 10mV/div.
Net weight (2.2 lb = 1 kg) 0.8 kg / 1 lb 12.2 oz (1.762 lb)
Price in first year of sale 2,180.00 DM
Source of data - - Manufacturers Literature

Model page created by Franz Harder. See "Data change" for further contributors.
