• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1972–1975

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 28778

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 16

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 7 AM circuit(s)     11 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 28 W (40 W max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Allegretto TS2020 - Telefunken Deutschland TFK,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 485 x 108 x 193 mm / 19.1 x 4.3 x 7.6 inch

• Notes
• ICs: 5.
  Stereo-Steuergerät. NF-Verstärker mit 2 Endstufen je 20 W (Musik); zwei Lautsprecherboxen L20 (260×108×193 mm, 2,5 kg) gehören zu Lieferumfang.

• Net weight (2.2 lb = 1 kg)
• 4 kg / 8 lb 13 oz (8.811 lb)

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1972/1973

• Mentioned in
• -- Original prospect or advert
