• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1980/1981

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 112011

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors
• 2SB700 2SD736 2SB700 2SD736 LM391 LM391

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: HiFi Stereo Main Amplifier STM1 - Telefunken Deutschland TFK,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 482 x 76 x 350 mm / 19 x 3 x 13.8 inch

• Notes
• Telefunken HiFi Stereo Main Amplifier STM1,
  HiFi-Endverstärker. Übertragungsbereich 5 - 58000 Hz, 2× 85 / 120 W an 4 Ohm; Front in Alu champagner-metallic oder metallic-braun, mit Frontgriffen. Der dazu passende Vorverstärker ist STP1.

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by Günther Stabe † 19.8.20. See "Data change" for further contributors.
