Super Platino FM

Super Platino FM ; Tonomac SAIC , (ID = 1245057) Radio Super Platino FM ; Tonomac SAIC , (ID = 1245059) Radio
Super Platino FM ; Tonomac SAIC , (ID = 1245062) Radio Super Platino FM ; Tonomac SAIC , (ID = 1246213) Radio
Super Platino FM ; Tonomac SAIC , (ID = 1246214) Radio Super Platino FM ; Tonomac SAIC , (ID = 1246824) Radio
Use red slider bar for more.
Super Platino FM ; Tonomac SAIC , (ID = 1245057) Radio
Tonomac SAIC ,: Super Platino FM [Radio] ID = 1245057 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super Platino FM, Tonomac SAIC , Buenos Aires

Country:  Argentina
Manufacturer / Brand:  Tonomac SAIC , Buenos Aires
Year: 1972 ?? Type: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8:
Principle Super-Heterodyne (Super in general)
Wave bands Broadcast, more than 2 SW bands plus FM.
Details
Power type and voltage Line / Batteries (any type) / 220 / 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: Super Platino FM - Tonomac SAIC , Buenos Aires
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (usable without mains)
Dimensions (WHD) 315 x 235 x 100 mm / 12.4 x 9.3 x 3.9 inch
Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)

Model page created by Luis Vila Krause. See "Data change" for further contributors.

All listed radios etc. from Tonomac SAIC , Buenos Aires
Here you find 10 models, 5 with images and 5 with schematics.
