• Country
• United States of America (USA)

• Manufacturer / Brand
• Triplett Electrical Instrument Co.; Bluffton (OH)

• Year
• 1951 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 97749

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• 6SJ7 6J6 6X5GT

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110-120 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Test Oscillator 3432 - Triplett Electrical Instrument

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 15.11 x 11.2 x 6.25 inch / 384 x 284 x 159 mm

• Notes
• Covers 165 kc to 120 mc in 7 ranges, 5 on fundamentals and 2 (36-120) on harmonics.

• Price in first year of sale
• 78.00 $

• Source of data
• -- Original-techn. papers.

• Literature/Schematics (1)
• 1951 Newark catalog Nº 51

• Author
• Model page created by Vitor Oliveira. See "Data change" for further contributors.
