SG560 Royal

SG560 Royal; Uher Werke; München (ID = 1398258) R-Player

SG560 Royal; Uher Werke; München (ID = 1398259) R-Player

SG560 Royal; Uher Werke; München (ID = 1398260) R-Player

SG560 Royal; Uher Werke; München (ID = 1398264) R-Player

SG560 Royal; Uher Werke; München (ID = 1398266) R-Player

SG560 Royal; Uher Werke; München (ID = 1398267) R-Player

SG560 Royal; Uher Werke; München (ID = 1398268) R-Player

SG560 Royal; Uher Werke; München (ID = 1398269) R-Player

SG560 Royal; Uher Werke; München (ID = 1398270) R-Player

SG560 Royal; Uher Werke; München (ID = 1398271) R-Player
SG560 Royal; Uher Werke; München (ID = 107957) R-Player SG560 Royal; Uher Werke; München (ID = 598898) R-Player
SG560 Royal; Uher Werke; München (ID = 598515) R-Player SG560 Royal; Uher Werke; München (ID = 598514) R-Player
SG560 Royal; Uher Werke; München (ID = 313847) R-Player SG560 Royal; Uher Werke; München (ID = 598513) R-Player
SG560 Royal; Uher Werke; München (ID = 598516) R-Player SG560 Royal; Uher Werke; München (ID = 598897) R-Player
SG560 Royal; Uher Werke; München (ID = 598899) R-Player SG560 Royal; Uher Werke; München (ID = 631856) R-Player
Use red slider bar for more.
SG560 Royal; Uher Werke; München (ID = 107957) R-Player
Uher Werke; München: SG560 Royal [R-Player] ID = 107957 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model SG560 Royal, Uher Werke; München

Country:  Germany
Manufacturer / Brand:  Uher Werke; München
Year: 1974–1977 Type: Recorder and/or Player
Semiconductors (the count is only for transistors) 40:
Principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 130; 150; 220; 240; 250 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: SG560 Royal - Uher Werke; München
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 465 x 188 x 350 mm / 18.3 x 7.4 x 13.8 inch
Notes HiFi-Stereo, Zweispur oder Vierspur durch auswechselbaren Kopfträger; Bandgeschwindigkeiten: 2,4/4,75/9,5/19 cm/s; Spulen-Ø: 18 cm; Übertragungsbereich: 20-20000 Hz bei 19 cm/s, 20-4500 Hz bei 2,4 cm/s; Stereo-NF-Verstärker mit 2 Endstufen je 10 W (Sinus), Antriebsmotor abschaltbar zur Verwendung als HiFi-Stereo-Verstärker. Gehäuse in Mattschwarz oder Nussbaum-Dekor.
Net weight (2.2 lb = 1 kg) 13.7 kg / 30 lb 2.8 oz (30.176 lb)
Collectors' prices
External source of data Erb
Source of data Katalog RFP 1974 / Radiokatalog Band 2, Ernst Erb
Mentioned in Handbuch VDRG 1975/1976 (und 1976/77)


All listed radios etc. from Uher Werke; München
Here you find 301 models, 267 with images and 153 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
