• Year
  • 1953–1956
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 72726

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 11
  • Main principle
  • Superhet with RF-stage; ZF/IF 465 kHz
  • Tuned circuits
  • 9 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and more than two Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 110-220 Volt
  • Loudspeaker
  • 2 Loudspeakers / Ø 20 cm = 7.9 inch
  • Power out
  • 4 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: MIR M-154 - VEF Radio Works Valst
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 720 x 470 x 370 mm / 28.3 x 18.5 x 14.6 inch
  • Net weight (2.2 lb = 1 kg)
  • 32.5 kg / 71 lb 9.4 oz (71.586 lb)
  • External source of data
  • Atis Brikmanis et.al.
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.
