165 Amplified Extension Speaker

165 Amplified Extension Speaker ; V-M VM Voice of (ID = 747200) Ampl/Mixer

165 Amplified Extension Speaker ; V-M VM Voice of (ID = 747201) Ampl/Mixer
165 Amplified Extension Speaker ; V-M VM Voice of (ID = 1006595) Ampl/Mixer 165 Amplified Extension Speaker ; V-M VM Voice of (ID = 1006593) Ampl/Mixer
165 Amplified Extension Speaker ; V-M VM Voice of (ID = 1006594) Ampl/Mixer 165 Amplified Extension Speaker ; V-M VM Voice of (ID = 1009795) Ampl/Mixer
165 Amplified Extension Speaker ; V-M VM Voice of (ID = 1009797) Ampl/Mixer 165 Amplified Extension Speaker ; V-M VM Voice of (ID = 1009799) Ampl/Mixer
165 Amplified Extension Speaker ; V-M VM Voice of (ID = 1009800) Ampl/Mixer 165 Amplified Extension Speaker ; V-M VM Voice of (ID = 1009801) Ampl/Mixer
165 Amplified Extension Speaker ; V-M VM Voice of (ID = 1009802) Ampl/Mixer 165 Amplified Extension Speaker ; V-M VM Voice of (ID = 1009803) Ampl/Mixer
Use red slider bar for more.
165 Amplified Extension Speaker ; V-M VM Voice of (ID = 1006595) Ampl/Mixer
V-M VM Voice of: 165 Amplified Extension Speaker [Ampl/Mixer] ID = 1006595 604x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model 165 Amplified Extension Speaker, V-M (VM) (Voice of Music) Corporation; Benton Harbor (MI):
By courtesy of guest Paul Thomas, Longwood, FL, USA. Was later painted as "a faux finish" on the exterior. A faux finish is different colors of paint applied by an artist using a sponge, and a very thin brush, to mimic the look of stone or rock, usually marble or granite.

Country:  United States of America (USA)
Manufacturer / Brand:  V-M (VM) (Voice of Music) Corporation; Benton Harbor (MI)
Year: 1958 Type: Audio Amplifier or -mixer
Valves / Tubes 3: 12AX7 6V6GT 6X4
Principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110 - 120 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: 165 Amplified Extension Speaker - V-M VM Voice of Music
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 24 x 9.125 x 12.5 inch / 610 x 232 x 318 mm
Notes The V-M Corp Model 165 is an AC operated 2 Tube Phono Amplifier plus one tube as power rectifier. It is called "Amplified Extension Speaker". There is a tube based amplifier in the loudspeaker 165. The label of it says "to replace tubes remove this cover". Guest Paul Thomas wrote us: "... shows the three knobs, which are on the side of the speaker. The top knob turns the amplifier on and off, and also controls the treble, the middle knob controls bass, and the bottom knob controls volume. Under the knobs you see two inputs, one saying "Microphone", which is where I used to plug in my guitar, and the other saying "Phono", which looks like the size of an RCA jack. I've never used that one."

The Photofact date 12-58, set 423, folder 23 shows the following models for the same schematic: V-M Models: 165, 166, 166A, 8809 and 8810. There is one picture but some of those models (like this one) look quite different. It is not given which model the picture represents - but here we have true pictures of model 165.
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 12-58, Set 423, Folder 23)

Model page created by Egon Penker. See "Data change" for further contributors.
