Lab Zero Tuner ; Wega, (ID = 1689531) Radio
Wega,: Lab Zero Tuner [Radio] ID = 1689531 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Lab Zero Tuner, Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach

Country:  Germany
Manufacturer / Brand:  Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach
alternative name

Württemb. Radio-Ges.mbH; Stuttgart
Year: 1978 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
schematic requested
Main principle Super-Heterodyne (Super in general)
Wave bands FM Broadcast Band Only
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Lab Zero Tuner - Wega, Württembergische Radio-
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 450 x 112 x 395 mm / 17.7 x 4.4 x 15.6 inch
Notes UKW-Empfänger mit 10-Gang-Drehko-abstimmung. Abstimmungsinstrumente Signalstärke, Ratio-Mitte, Multipath.
Frequenzdisplay umschaltbar auf Kanalanzeige. Narrow- und wide-Selektivität.
Anschluss für Oszilloskop.
NF-Ausgang: 775mV/0.02kOhm, regelbar.
Price in first year of sale 3,900.00 DM
Source of data -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.
