• Year
  • 1985 ??
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 225617
    • alternative name: Württemb. Radio-Ges.mbH; Stuttgart

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Details
  • Radio Control (+Remote Wire etc)
  • Power type and voltage
  • Alternating Current supply (AC) / 110-240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Video Modul Tuner/Timer TT50 - Wega, Württembergische Radio-
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 215 x 80 x 325 mm / 8.5 x 3.1 x 12.8 inch
  • Notes
  • Tuner und Timer-Modul für Wega Video Modul R50

    Tuner E2-E12, E21-E86; CCIR B/G und PAL
    12 Stationstasten
    Timer-Funktion zur automatischen Aufzeichnung mit R50
    9 Timer-Speicherprogramme

    26-pin Anschluss für R50
    BNC Video-Ein- und Ausgang
    Cinch Audio-Ein- und Ausgang
    HF-Modulationsausgang
