6D-312W ivory finish
Zenith Radio Corp.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Zenith Radio Corp.; Chicago, IL
- Year
- 1938/1939
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 238307
-
- alternative name: Chicago Radio Lab
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 115 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
- Material
- Bakelite case
- from Radiomuseum.org
- Model: 6D-312W [ivory finish] - Zenith Radio Corp.; Chicago,
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 12.5 x 7.8 x 6.4 inch / 318 x 198 x 163 mm
- Notes
-
Ivory finish. Same model in Brown bakelite: model 6D312.
Unknown ballast tube.
- Mentioned in
- Table Top Radios Vol. 1 Stein 98 (page 170.)
- Literature/Schematics (1)
- Rider's Perpetual, Volume 9 = 1938 and before
- Author
- Model page created by Noemi Erb. See "Data change" for further contributors.
