For model 8S661 8-S-661 Ch=8B01, Zenith Radio Corp.; Chicago, Illinois:
Copy gen. von John Goller Radio Attic

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, Illinois
alternative name

Chicago Radio Lab
Year: 1942 Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 7H7 6A8G 6SK7GT 6SQ7GT 6J5G 6F6G 6F6G 5Y4G
Principle Superhet with RF-stage; ZF/IF 455 kHz
Wave bands Broadcast, Short Wave(s) and Police.
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 14 inch = 35.6 cm
Power out
from Radiomuseum.org Model: 8S661 8-S-661 Ch=8B01 - Zenith Radio Corp.; Chicago,
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 27.8 x 40 x 12.3 inch / 706 x 1016 x 312 mm
Price in first year of sale 90.00 $
Collectors' prices
External source of data Ernst Erb
Source of data The Radio CollectorGrinder, 1995
Circuit diagram reference Rider's Perpetual, Volume 13 = 1942 and before
Mentioned in Collector's Guide to AR4.Ed.,Bunis, tube
Literature/Schematics (1) Zenith The Glory Years, Cones,03
Literature/Schematics (2) Pre-War Consoles; Stein, 2000
