B1413GZU Ch= 15B20U; Zenith Radio Corp.; (ID = 1933985) Television
Zenith Radio Corp.;: B1413GZU Ch= 15B20U [Television] ID = 1933985 504x682
Select picture or schematic to display from thumbnails on the right and click for download.
For model B1413GZU Ch= 15B20U, Zenith Radio Corp.; Chicago, IL:
USA_Zenith_B1413G_front.

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1958 Category: Television Receiver (TV) or Monitor
Valves / Tubes 16: 14AUP4
Main principle Superhet with RF-stage
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 110 - 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: B1413GZU Ch= 15B20U - Zenith Radio Corp.; Chicago,
Notes 14" b/w TV with US standard VHF Tuner Channels 2 thru 13, 14 thru 83 UHF.
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 1-59, Set 426, Folder 3)

Model page created by Egon Penker. See "Data change" for further contributors.



All listed radios etc. from Zenith Radio Corp.; Chicago, IL
Here you find 3865 models, 3184 with images and 3024 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
