Trans-Oceanic (TransOceanic) H500 Ch= 5H40 (undefined variant)

Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 240727) Radio

Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 240728) Radio

Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 240729) Radio

Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 240730) Radio
Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 50018) Radio Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 50058) Radio
Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 1251878) Radio Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 411091) Radio
Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 422291) Radio Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 422292) Radio
Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 51042) Radio Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 612137) Radio
Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 735202) Radio Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 735203) Radio
Use red slider bar for more.
Trans-Oceanic H500 Ch= 5H40 ; Zenith Radio Corp.; (ID = 50018) Radio
Zenith Radio Corp.;: Trans-Oceanic H500 Ch= 5H40 [Radio] ID = 50018 303x316
Select picture or schematic to display from thumbnails on the right and click for download.
For model Trans-Oceanic (TransOceanic) H500 Ch= 5H40 (undefined variant), Zenith Radio Corp.; Chicago, Illinois:
Gerät nicht mehr in meinem Besitz.

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, Illinois
alternative name

Chicago Radio Lab
Year: 1951–1953 Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 1U4 1L6 1U4 1S5 or 1U5 3V4
Principle Superhet with RF-stage; ZF/IF 455 kHz
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Line / Batteries (any type) / AC/DC 110; 220; Batt.9 & 90 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.25 inch = 13.3 cm
Power out
from Radiomuseum.org Model: Trans-Oceanic H500 Ch= 5H40 - Zenith Radio Corp.; Chicago,
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (usable without mains)
Dimensions (WHD) 430 x 280 x 200 mm / 16.9 x 11 x 7.9 inch
Notes The different revision versions can only be distinguished if the chassis back is visible. Here is the place for such undefined set pictures.

See also the article here.
Siehe auch den Artikel hier.
Si veda anche l'articolo in questa pagina. Battery Pack No. Z-985 ( 9 & 90 V DC). 220 V mains only with power adapter inserted.
Collectors' prices
External source of data Ernst Erb
Source of data The Radio CollectorGrinder, 1995
Circuit diagram reference Rider's Perpetual, Volume 22, covering 1951
Mentioned in Collector's Guide to AR4.Ed.,Bunis, tube
Literature/Schematics (1) Bryant/Cones: The Zenith Trans-Oceanic


All listed radios etc. from Zenith Radio Corp.; Chicago, Illinois
Here you find 3595 models, 2664 with images and 2735 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Zenith Radio Corp.;: Trans-Oceanic H500 Ch= 5H40
Threads: 4 | Posts: 4
Hits: 1957     Replies: 0
zenith: Zenith Trans-Oceanic H500: variations
Martin Bösch
13.Sep.08
  1

When I compared the two H500 Trans Oceanics from my collection, there is a remarkable difference concerning the power supply:



On one set, I find the power selector for 110 V AC-DC, 220 V DC and 220 V AC;

between the power lead and the phones jack, there is a switch labelled "SEE INSTRUCTION BOOK".

On the other Set, I find no such selector;

there is no switch, but there is "INSERT A.C. PLUG HERE FOR BATTERY OPERATION" engraved in the chassis.

The model with the power selector (with the black cabinet (power resistor ?) is the one found in J. Bryant and H. Cones' Book, the other model is the one found in Sam's Photofact (found at BAMA), it has no traces of the switch having been removed, so I consider it two genuine variants.

You may encounter both models when having a look at the images from our members.
Kind regards Martin Boesch


Hits: 1268     Replies: 0
zenith: H500; Trans-Oceanic
Konrad Birkner † 12.08.2014
30.Mar.04
  1 Der Einführungspreis von $ 99,95 stieg bis zur Weihnachtssaison 1951 auf $ 124,25, wo er dann gehalten wurde.

Hits: 1190     Replies: 0
zenith: H500; 5H40
Ralf Sürtenich
23.Mar.04
  1 There was in 1953 a 5th edition (Revision D) of H500 with an additional socket for an optional 50A1 voltage regulator tube. In the empty socket was a jumper plug which enables a 1.200 ohm resistor when no 50A1 was used. So with the installed 700 ohm restistor and the additional 1.200 ohm resistor the heater circuit had the same resistance like the standard H500 circuit with 2 * 950 ohm resistors.

It's likely this last H500 edition was a test series for the RR-520 or it were just spare chassis of this which were used in the standard H500 cabinet. But in difference to RR-520 this chassis isn't using tube shields or a shielded RF-head, and it has no dial light.

Hits: 1168     Replies: 0
zenith: H500; 5H40
Konrad Birkner † 12.08.2014
23.Mar.04
  1 $ 99.95 was the introductory price which then jumped up to $ 124.25 for Christmas 1951 and later.

Zenith Radio Corp.;: Trans-Oceanic H500 Ch= 5H40
End of forum contributions about this model
