12CU6

Information - Help
ID = 5346

Country:
United States of America (USA)
Brand:
Tube type:  Beam Power Tube   Power/Output
Identical to 12CU6 = 12BQ6GTB
Similar Tubes
Heater different:
  25BQ6GTB ; 25CU6 ; 6BQ6GTB ; 6CU6

Base Octal (Int.Octal, IO) K8A, USA 1935 Top contact with a cap.
Was used by Radio/TV-reception etc.
Filament Vf 12.6 Volts / If 0.6 Ampere / Indirect / Specified voltage AC/DC
Tube prices 2 Tube prices (visible for members only)
Information source Essential Characteristics, GE 1973

12CU6: Courtesy Bureau Belper (De Muiderkring, Bussum), Scan Frank Philipse
Karel De Reus †

oc55_3.png 12CU6: RTT 1974 (Franzis) 13. Auflage
Martin Renz


Just Qvigstad
12CU6: RCA Tube Manual
Peter Hoddow

Usage in Models 60= 1955? ; 10= 1955 ; 583= 1956? ; 100= 1957? ; 4= 1958? ; 1= 1970?

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):758
