6G6

Information - Help
ID = 10636

Country:
United States of America (USA)
Brand: Common type USA tube/semicond.
Tube type:  Vacuum Pentode   Power/Output
Identical to 6G6

Base Octal (Int.Octal, IO) K8A, USA 1935 (Codex=Udo)
Filament Vf 6.3 Volts / If 0.15 Ampere / Specified voltage AND current AC/DC
Information source Taschenbuch zum Röhren-Codex 1948/49

6G6: Courtesy Bureau Belper (De Muiderkring, Bussum), Scan Frank Philipse
Anonymous 10 Collector

365_1.png 6G6: Telefunken Werkstattbuch
Wolfgang Bauer


Just Qvigstad
6G6: elektron taschenbuch 1952
Heinz Höger

Usage in Models 1= 1937 ; 1= 1938 ; 2= 1939 ; 3= 1940 ; 1= 1941?? ; 3= 1945?? ; 1= 1945? ; 1= 1947 ; 2= 1948?? ; 1= 1949 ; 2= 1950??

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):18
