BC560

Information - Help
ID = 35880

Country:
Europe
Brand: Common type Europe tube/semicond.
Tube type:  Transistor   Universal
Identical to BC560
Similar Tubes
Normally replaceable-slightly different:
  2N3964 ; 2N4289 ; 2SA836 ; BC214 ; BC225 ; BC315 ; BC325 ; BC326 ; BC416 ; BC557 ; BFX65 ; CS1312 ; CS9015 ; OC207
Other base and data slightly different:
  2SA828 ; BC478 ; BC479 ; DW6089 ; DW7975

Base Wires
Filament Solid State /
Description PNP silicon planar-epitaxial transistor for general purposes.

Text in other languages (may differ)
Dimensions (WHD)
incl. pins / tip
5 x 5 x 4 mm / 0.20 x 0.20 x 0.16 inch
Weight 1 g / 0.04 oz
Literature -- Collector info (Sammler)   TVT 1979/80 ECA, TTT Steidle 1981


BC560: P.ST
Peter Steffen


BC560: TTT Steidle 1981
Günther Stabe


BC560: Valvo Transistoren, 1974
Michael Schlör


Usage in Models 1= 1977 ; 3= 1978 ; 1= 1979?? ; 1= 1980 ; 3= 1981? ; 1= 1981 ; 1= 1982 ; 3= 1983 ; 3= 1984 ; 1= 1985? ; 1= 1986?? ; 1= 1988 ; 1= 1994? ; 1= 1994
