EBC90

Information - Help
ID = 3545

Country:
Europe
Brand: Common type Europe tube/semicond.
Tube type:  Double Diode-Triode   Audio Frequency
Identical to EBC90 = DH77 = CV452 = 6AT6
Similar Tubes
Other shape (e.g. bulb type):
  6BT6
Other class quality (otherwise equal):
  6066
Heater different:
  12AT6 ; HBC90
Heater and shape different:
  12BT6
Other base and other heater:
  EBC81
Successor Tubes EBC91
Base Miniatur-7-Pin-Base B7G, USA 1940
Filament Vf 6.3 Volts / If 0.3 Ampere / Indirect / Specified voltage AND current AC/DC
Dimensions (WHD)
incl. pins / tip		 19 x 48 x mm / 0.75 x 1.89 x inch
Tube prices 3 Tube prices (visible for members only)
EBC90: Courtesy Bureau Belper (De Muiderkring, Bussum), Scan Frank Philipse
Karel De Reus †
mi6.png EBC90: RTT 1974 (Franzis) 13. Auflage
Martin Renz
More ...
Just Qvigstad 		ebc90_mullard_data_01.png
EBC90: Mullard - original papers
Michael Poll
More ...
Usage in Models 1= 1952? ; 2= 1953?? ; 1= 1953? ; 3= 1954 ; 4= 1955?? ; 1= 1955? ; 1= 1956?? ; 1= 1956? ; 11= 1956 ; 1= 1957?? ; 11= 1957 ; 2= 1958? ; 13= 1958 ; 4= 1959 ; 1= 1960 ; 1= 1961
Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):58
