Registratore Alta Fedeltà G258
Geloso SA; Milano: Registratore Alta Fedeltà G258 [R-Player] ID = 322446 819x614
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1959 | Category: Sound/Video Recorder and/or Player | ||||
| Valves / Tubes | 4: 12AX7 or ECC83 12AX7 or ECC83 EM84 EL95 | ||||
|---|---|---|---|---|---|
| Semiconductors (the count is only for transistors) | B250C100 B30C250 |
| Main principle | Audio-Amplification |
|---|---|
| Wave bands | - without |
| Details | Tape Recorder |
| Power type and voltage | Alternating Current supply (AC) / 110; 125; 160; 220 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical |
| Power out | 2.5 W (unknown quality) |
| from Radiomuseum.org | Model: Registratore Alta Fedeltà G258 - Geloso SA; Milano |
| Material | Plastics (no bakelite or catalin) |
| Shape | Tablemodel without push buttons, Mantel/Midget/Compact up to 14 |
| Dimensions (WHD) | 330 x 160 x 220 mm / 13 x 6.3 x 8.7 inch |
| Notes | Velocità: 9,5 / 4,75 / 2,38 cm/s. Controllo in cuffia della registrazione. Gli esemplari più recenti usavano una 6AQ5 al posto della EL95, come il modello successivo G268. |
| Net weight (2.2 lb = 1 kg) | 5 kg / 11 lb 0.2 oz (11.013 lb) |
| Price in first year of sale | 59'000.00 LIT |
| Mentioned in | Bollettino Tecnico Geloso (n. 77) |
| Literature/Schematics (1) | -- Original-techn. papers. (D.E. Ravalico: L'Audiolibro. Quinta Edizione. Hoepli, Milano, 1962.) |
| Literature/Schematics (2) | -- Schematic (L'Audio Libro D.E. Ravalico VI edizione - Hoepli - 1965) |
