FM-Concert-Boy 55 USA
Grundig (Radio-Vertrieb, RVF, Radiowerke)
- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke)
- Year
- 1955
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 279426
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
- Number of Tubes
- 9
- Main principle
- Superheterodyne (common); ZF/IF 468/10700 kHz; Export model
- Tuned circuits
- 8 AM circuit(s) 12 FM circuit(s)
- Wave bands
- Broadcast, 2 Short Wave plus FM or UHF.
- Power type and voltage
- Line / Batteries (any type) / 110; 220 / 1,5 & 90 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: FM-Concert-Boy 55 USA - Grundig Radio-Vertrieb, RVF,
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 425 x 260 x 170 mm / 16.7 x 10.2 x 6.7 inch
- Notes
-
Grundig FM Concert Boy 55 USA is an export model for the U.S.A.
Wave bands:- FM 88 ... 108 MHz
- SW 1 5.9 ... 11.8 MHz
- SW 2 11 ... 19 MHz
- BC/MW 510 ... 1620 kHz, with CD-marks, please refer to the forum's article
Conelrad: Radio meets the Civil Defense
See also the domestic model UKW-Concert-Boy 55 with LW, MW, SW and UKW/FM.
Grundig FM Concert Boy 55 USA ist ein Exportmodell für die USA. Erweiterter UKW/FM Bereich bis 108 MHz, 2x KW und MW, kein LW-Bereich.
Bei Netzbetrieb arbeitet die EL42 als NF-Endstufe.
- Net weight (2.2 lb = 1 kg)
- 6.2 kg / 13 lb 10.5 oz (13.656 lb)
- Author
- Model page created by Michael Gnaedig-Fischer. See "Data change" for further contributors.
