Musikschrank 7000 (2042)

Musikschrank 7000 ; Grundig Radio- (ID = 34970) Radio

Musikschrank 7000 ; Grundig Radio- (ID = 374113) Radio

Musikschrank 7000 ; Grundig Radio- (ID = 374114) Radio

Musikschrank 7000 ; Grundig Radio- (ID = 374115) Radio

Musikschrank 7000 ; Grundig Radio- (ID = 374116) Radio
Musikschrank 7000 ; Grundig Radio- (ID = 32376) Radio Musikschrank 7000 ; Grundig Radio- (ID = 32377) Radio
Musikschrank 7000 ; Grundig Radio- (ID = 32379) Radio Musikschrank 7000 ; Grundig Radio- (ID = 1177496) Radio
Musikschrank 7000 ; Grundig Radio- (ID = 1523864) Radio Musikschrank 7000 ; Grundig Radio- (ID = 1523865) Radio
Musikschrank 7000 ; Grundig Radio- (ID = 2145647) Radio Musikschrank 7000 ; Grundig Radio- (ID = 2145648) Radio
Musikschrank 7000 ; Grundig Radio- (ID = 2145649) Radio Musikschrank 7000 ; Grundig Radio- (ID = 2145650) Radio
Use red slider bar for more.
Musikschrank 7000 ; Grundig Radio- (ID = 32376) Radio
Grundig Radio-: Musikschrank 7000 [Radio] ID = 32376 441x506
Select picture or schematic to display from thumbnails on the right and click for download.
For model Musikschrank 7000 (2042), Grundig (Radio-Vertrieb, RVF, Radiowerke):
Sammlung Ortjohann

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1957/1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM34 or EM35 EL84
Main principle Super-Heterodyne (Super in general)
Tuned circuits 7 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 125; 160; 220 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Musikschrank 7000 - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 640 x 780 x 390 mm / 25.2 x 30.7 x 15.4 inch
Notes Phono-Chassis = Monarch TC8M. Die Version "hell" kostete 614 DM.
Nach einer Aufstellung von Hans M. Knoll (dem damaligen Entwickler bei Grundig) gibt es das Modell zusätzlich in verschiedenen Exportvarianten, die wir in Englisch beschreiben - und angelegt haben.

The Grundig Musikschrank 7000 with design number 2042 was made for domestc purpose (or German speaking countries) in two wood colors ("hell" or "dunkel"). According to Mr. Hans M. Knoll (former Grundig designer) the following export models were made: Grundig-Majestic = 7000USA with design number Z. 2042-100; 7000S SEMKO for Sweden with design number Z. 2042-200; for Italy 7000I (Z 2042-300); Export for AM only 7000WE (Z. 2042-500).
Net weight (2.2 lb = 1 kg) 32.5 kg / 71 lb 9.4 oz (71.586 lb)
Price in first year of sale 598.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1957/58


All listed radios etc. from Grundig (Radio-Vertrieb, RVF, Radiowerke)
Here you find 6005 models, 5214 with images and 4047 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Grundig Radio-: Musikschrank 7000
Threads: 1 | Posts: 1
Hits: 529     Replies: 0
grundig: Typing error on tuning scale?
Georges Van Campenhout
12.Sep.17
  1

Dear Forum members



I found this strange typing error on a tuning scale of a Grundig 7000 radio chassis:

AFN. STUTTGARTT, although the last T is not complete.

Is this a mistake or has it a special meaning?



Best regards

Attachments


Grundig Radio-: Musikschrank 7000
