Hiphonic Super Sensitivity KH-1002R

Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 775043) Radio

Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 775044) Radio

Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 2549935) Radio

Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 2549936) Radio
Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 2293118) Radio Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 2293119) Radio
Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 1913032) Radio Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 1913034) Radio
Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 575271) Radio Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 1913033) Radio
Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 1913035) Radio Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 1913036) Radio
Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 2482022) Radio Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 2482023) Radio
Use red slider bar for more.
Hiphonic Super Sensitivity KH-1002R; Hitachi Ltd.; Tokyo (ID = 2293118) Radio
Hitachi Ltd.; Tokyo: Hiphonic Super Sensitivity KH-1002R [Radio] ID = 2293118 1400x1316
Select picture or schematic to display from thumbnails on the right and click for download.
For model Hiphonic Super Sensitivity KH-1002R, Hitachi Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Hitachi Ltd.; Tokyo
alternative name

Hitachi Sales Corp. of America
Year: 1965 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: 2SA235 2SA235 2SA350 2SA350 2SA350 2SB75 2SB155 2SB155 2SB156 2SB156
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz; 4 AF stage(s)
Tuned circuits 5 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Hiphonic Super Sensitivity KH-1002R - Hitachi Ltd.; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes Hitachi KH-1002R Hiphonic Super Sensitivity;
AM/FM three bands, two earphone jacks.
Circuit diagram reference Radio and TV Servicing books (R&TVS) book

Model page created by a member from A. See "Data change" for further contributors.
