King W503AT /30 /70

King W503AT; Horny Hornyphon; (ID = 783113) Radio

King W503AT; Horny Hornyphon; (ID = 783114) Radio

King W503AT; Horny Hornyphon; (ID = 783115) Radio

King W503AT; Horny Hornyphon; (ID = 930755) Radio

King W503AT; Horny Hornyphon; (ID = 930754) Radio

King W503AT; Horny Hornyphon; (ID = 1896677) Radio
King W503AT; Horny Hornyphon; (ID = 2244348) Radio King W503AT; Horny Hornyphon; (ID = 2244347) Radio
King W503AT; Horny Hornyphon; (ID = 2244349) Radio King W503AT; Horny Hornyphon; (ID = 2244352) Radio
King W503AT; Horny Hornyphon; (ID = 2244350) Radio King W503AT; Horny Hornyphon; (ID = 2244351) Radio
King W503AT; Horny Hornyphon; (ID = 1764111) Radio King W503AT; Horny Hornyphon; (ID = 1049169) Radio
King W503AT; Horny Hornyphon; (ID = 1049171) Radio King W503AT; Horny Hornyphon; (ID = 70015) Radio
Use red slider bar for more.
King W503AT; Horny Hornyphon; (ID = 2244348) Radio
Horny Hornyphon;: King W503AT [Radio] ID = 2244348 1382x905
Select picture or schematic to display from thumbnails on the right and click for download.
For model King W503AT /30 /70, Horny (Hornyphon); Wien

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1963/1964 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: AF114 AF115 AF116 AF116 AF116 AF117 AC126 AC126 AC128 OC26
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz; 4 AF stage(s)
Tuned circuits 9 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2.8 W (unknown quality)
from Radiomuseum.org Model: King W503AT [/30 /70] - Horny Hornyphon; Wien
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 540 x 270 x 190 mm / 21.3 x 10.6 x 7.5 inch
Notes 2 Ausführungen: /30 = dunkel-glänzend, /70 = hell-matt
Parallelgerät zum Philips B5W32AT.
Net weight (2.2 lb = 1 kg) 5.4 kg / 11 lb 14.3 oz (11.894 lb)
Price in first year of sale 2'870.00 ATS
Source of data -- Original prospect or advert / Radiokatalog Band 2, Ernst Erb
Mentioned in -- Original-techn. papers.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
