For model WT1711A Ch= C1, Horny (Hornyphon); Wien:
Detailbild aus nachstehender Werbeschaltung, hochgeladen von Herrn Hannes Wurnitsch.

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1954–1956 Category: Television Receiver (TV) or Monitor
Valves / Tubes 22: PCC84 PCF80 EF80 EF80 EF80 EF80 PL83 EF80 ECH81 EF80 PABC80 PL82 ECL80 ECL80 PL82 ECL80 PL81 PY81 EY51 PY82 PY82 MW43-69
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: WT1711A Ch= C1 - Horny Hornyphon; Wien
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 540 x 490 x 590 mm / 21.3 x 19.3 x 23.2 inch
Notes

Empfangsbereich: Band I + III, Kanal 2a - 4, 5 - 12.

Paralleltype zum Philips 17TA111A.

Net weight (2.2 lb = 1 kg) 31 kg / 68 lb 4.5 oz (68.282 lb)
Price in first year of sale 7'500.00 öS
Source of data -- Original prospect or advert / Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
