High Voltage Power Supply UHR-220
Krohn-Hite Corp.; Cambridge and Brockton, MA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Krohn-Hite Corp.; Cambridge and Brockton, MA
- Year
- 1955–1965 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 236663
- Number of Tubes
- 7
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 115, 230, 250 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: High Voltage Power Supply UHR-220 - Krohn-Hite Corp.; Cambridge
- Dimensions (WHD)
- 7 x 10 x 15 inch / 178 x 254 x 381 mm
- Notes
-
Ultra High Regulation Power Supply.
Main DC Output: 0 - 500V (continuously adjustable without switching), max 200 mA. DC Bias Output: 0 - 150V (continuously adjustable), max 5 mA. AC Output: 2x 6,3V, max 5A.
- Net weight (2.2 lb = 1 kg)
- 50 lb (50 lb 0 oz) / 22.7 kg
- Mentioned in
- - - Manufacturers Literature
- Author
- Model page created by Massimo Follaro. See "Data change" for further contributors.
