SSB Amateur Band Receiver KW202

K.W. Electronics Ltd.; Dartford

Data
Forum
Pictures
Collections

  • Year
  • 1971 ?
  • Category
  • Amateur-Receiver (amateur bands, may include broadcast bands)
  • Radiomuseum.org ID
  • 337311

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 13
  • Number of Transistors
  • 1
  • Main principle
  • Superhet, double/triple conversion; ZF/IF 455 kHz
  • Wave bands
  • Short Wave (SW only)
  • Power type and voltage
  • Alternating Current supply (AC) / 200-240 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Power out
  • 1.5 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: SSB Amateur Band Receiver KW202 - K.W. Electronics Ltd.;
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 352 x 158 x 336 mm / 13.9 x 6.2 x 13.2 inch
  • Notes

  • SSB Amateur Band Receiver.

    • 1.8 MHz - 30 MHz in 9 bands.
    • SSB/AM/ CW, with Mechanical Filter.
    • Built-in 'Q' Multiplier (Peak & Null).
    • 500 kHz VFO covering all Bands.
    • Two-Speed VFO Drive.
    • Sensitivity better than 1µV for 500 mW output.
  • Net weight (2.2 lb = 1 kg)
  • 8 kg / 17 lb 9.9 oz (17.621 lb)
  • Price in first year of sale
  • 140.00 GB £
  • Mentioned in
  • -- Original prospect or advert (Da: “Radio Rivista” organo ufficiale dell’ARI Italia, numero 1, gennaio 1975.)
  • Author
  • Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
