Transita 2354 983.103H

Transita 2354 983.103H; Nordmende, (ID = 679819) Radio

Transita 2354 983.103H; Nordmende, (ID = 679820) Radio

Transita 2354 983.103H; Nordmende, (ID = 679821) Radio

Transita 2354 983.103H; Nordmende, (ID = 679989) Radio
Transita 2354 983.103H; Nordmende, (ID = 1077431) Radio Transita 2354 983.103H; Nordmende, (ID = 679721) Radio
Transita 2354 983.103H; Nordmende, (ID = 1480002) Radio Transita 2354 983.103H; Nordmende, (ID = 1480003) Radio
Transita 2354 983.103H; Nordmende, (ID = 1480004) Radio Transita 2354 983.103H; Nordmende, (ID = 1480005) Radio
Transita 2354 983.103H; Nordmende, (ID = 1480006) Radio Transita 2354 983.103H; Nordmende, (ID = 1480007) Radio
Use red slider bar for more.
Transita 2354 983.103H; Nordmende, (ID = 1077431) Radio
Nordmende,: Transita 2354 983.103H [Radio] ID = 1077431 704x615
Select picture or schematic to display from thumbnails on the right and click for download.
For model Transita 2354 983.103H, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen:
Nordmende TV-Video-HiFi-Radio 1983/84

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1983 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: 2SC1923 2SC1923 2SC1923 2SA1015 AN7223 LM1895 2SC1815 2SC1815 2SA1015 2SC1815
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220; 4 × 1,5 Volt
Loudspeaker 2 Loudspeakers
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Transita 2354 983.103H - Nordmende, Norddeutsche Mende-
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 283 x 168 x 87 mm / 11.1 x 6.6 x 3.4 inch
Notes UKW: 87,5 - 108 MHz
KW: 5900 - 18000 kHz
MW: 525 - 1620 kHz
LW: 150 - 270 kHz
Net weight (2.2 lb = 1 kg) 1.2 kg / 2 lb 10.3 oz (2.643 lb)
Source of data - - Data from my own collection
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) - - Manufacturers Literature

Model page created by Guido Höh. See "Data change" for further contributors.
