For model St. James 2 Auto Ch= X359 type B, Optalix, T.E.D.; Amiens, Paris, Aubervilliers:
Optalix St. James Auto Type S.2 - Beige - Ursprung: Klaus R. Tiefenbacher

Country:  France
Manufacturer / Brand:  Optalix, T.E.D.; Amiens, Paris, Aubervilliers
alternative name

TED, Technique et Décoration
Year: 1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: SFT320 AF127 AF127 AC125 AC132 AC132 OA90
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 2 x 4.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.7 cm = 3 inch
Power out 0.275 W (unknown quality)
from Radiomuseum.org Model: St. James 2 Auto Ch= X359 [type B] - Optalix, T.E.D.; Amiens, Paris
Material Leather / canvas / plastic - over other material
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 186 x 105 x 60 mm / 7.3 x 4.1 x 2.4 inch
Notes

2 gammes d'ondes : PO de 185 à 578 m, GO de 1110 à 2000 m. Cadre ferrocapteur de 14 cm. Prises écouteur avec coupure du HP intérieur (Z = 25 ohms) et antenne-voiture commutée.

Coffret en deux coquilles en matière moulée incassable, gainé en skai.

Type B : circuit imprimé X359-68, commutation antenne-cadre. Voir aussi documents techniques.

Net weight (2.2 lb = 1 kg) 0.830 kg / 1 lb 13.3 oz (1.828 lb)
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) -- Original prospect or advert
Literature/Schematics (2) - - Manufacturers Literature (Catalogue pièces de rechange, 1972-1973)

Model page created by Mark Hippenstiel. See "Data change" for further contributors.
