Globetrotter 522 22RR522

Globetrotter 522 22RR522; Philips - Österreich (ID = 282936) Radio

Globetrotter 522 22RR522; Philips - Österreich (ID = 282938) Radio

Globetrotter 522 22RR522; Philips - Österreich (ID = 677042) Radio

Globetrotter 522 22RR522; Philips - Österreich (ID = 677043) Radio
Globetrotter 522 22RR522; Philips - Österreich (ID = 115179) Radio Globetrotter 522 22RR522; Philips - Österreich (ID = 156275) Radio
Globetrotter 522 22RR522; Philips - Österreich (ID = 156276) Radio Globetrotter 522 22RR522; Philips - Österreich (ID = 1830122) Radio
Use red slider bar for more.
Globetrotter 522 22RR522; Philips - Österreich (ID = 115179) Radio
Philips - Österreich: Globetrotter 522 22RR522 [Radio] ID = 115179 864x656
Select picture or schematic to display from thumbnails on the right and click for download.
For model Globetrotter 522 22RR522, Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1973 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 21:
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 110; 220 / 6 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Globetrotter 522 22RR522 - Philips - Österreich
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 360 x 210 x 90 mm / 14.2 x 8.3 x 3.5 inch
Notes Paralleltype zum Horny Rio SX8522.
Siehe auch unter Philips-Deutschland 22RR522
Net weight (2.2 lb = 1 kg) 3.2 kg / 7 lb 0.8 oz (7.048 lb)
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.



All listed radios etc. from Philips - Österreich
Here you find 1057 models, 992 with images and 849 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Philips - Österreich: Globetrotter 522 22RR522
Threads: 1 | Posts: 6
Hits: 2391     Replies: 5
philips: 22RR522; Globetrotter 522
Felice Nicolini
03.Sep.10
  1

 Good afternoon.

I have photos of the model indicated in the title, but could instead relate to the corresponding German model  Radio Recorder 522. I see no evidence, neither on Radiomuseum nor on my equipment, for a safe assignment. Within the first radio cassette, is on the plate: "Type: 22RR522/19R", while on the variable capacitor is the label:

TC05 22RR522/19R,
460KC 74 425
163509.

The other radio cassette:
TC02 22RR522/19R

460KC 77 342
39631.

Thank you

Wolfgang Bauer
03.Sep.10
  2

Hallo Mr. Nicolini,

can you see where the device was built?
Made in Austria, Germany or Netherland?

Regards WB.

Felice Nicolini
03.Sep.10
  3



Behind, on the right, where the handle at rest stops, there is written, very small- on the boths radio recorders- "made in Holland".

What do i do?

Thank you.



Wolfgang Bauer
04.Sep.10
  4

Please create a new model built by Philips Nederland.

Regards WB.

Felice Nicolini
08.Sep.10
  5



Thanks for the answer.

I doubt however, that following this path the number of models from Philips will grow much. For example, I have two radio cassette:

-22RR622/59

with little written on the bottom, outside, "MADE IN HOLLAND";

-22RR645/19

marked "MADE IN HOLLAND" on a label near the battery compartment.

Now, you can verify that one is currently logged -on Radiomuseum-
 on Philips Deutschland and on Philips Oesterreich, while the latter only on Philips Oesterreich. Neither is currently recorded on Philips Holland.

Thank you.



Wolfgang Bauer
09.Sep.10
  6

Never mind.
Especially for Philips, there are many production sites.
Each new country of production of a model must be documented.
Please place your three new devices to Philips Holland.

Regards WB.


Philips - Österreich: Globetrotter 522 22RR522
End of forum contributions about this model
