• Country
• Germany

• Manufacturer / Brand
• Siemens (& Halske, -Schuckert Werke SSW, Electrogeräte); Berlin, München

• Year
• 1936 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 152326

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• - - No sound reproduction output.

• Material
• Various materials

• from Radiomuseum.org
• Model: Kapazitäts-Meßbrücke Rel msbr 16a - Siemens & Halske, -Schuckert

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 510 x 270 x 270 mm / 20.1 x 10.6 x 10.6 inch

• Notes
• Meßbereich 0,01pF bis 1µF

• Net weight (2.2 lb = 1 kg)
• 18 kg / 39 lb 10.4 oz (39.648 lb)

• Price in first year of sale
• 3,000.00 RM

• Mentioned in
• Siemens Messeinrichtungen für die Fernmeldetechnik 1940

• Literature/Schematics (1)
• Messgeräte für die Fernmeldetechnik, Siemens Juli 1936

• Author
• Model page created by Folkert Rothe. See "Data change" for further contributors.
