• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1997 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 135985

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 220-230 / D: 6 x 1,5 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 9 cm = 3.5 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 3 Band Stereo Radio Recorder RC 735 - Telefunken Deutschland TFK,

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 450 x 150 x 125 mm / 17.7 x 5.9 x 4.9 inch

• Notes
• 3 Band Stereo Radiorecorder RC 735
  UKW 88 bis 108 MHz, KW 60 bis 180 MHz, MW 550 bis 1600 kHz, Mono/Stereo-Schalter, drei Band Graphic Equalizer, Cassetten automatic stop, eingebautes Micro, Kopfhörer-Buchse, umschalter Netz/Batterie, Teleskopantenne.

• Net weight (2.2 lb = 1 kg)
• 3.6 kg / 7 lb 14.9 oz (7.93 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Karlheinz Fischer. See "Data change" for further contributors.
