• Country
• Spain

• Manufacturer / Brand
• Thomson Española S.A.; Thomson General Eléctrica; Cedosa; Electa; Setelsa; Madrid

• Year
• 1982 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 317956

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 14

• Semiconductors
• 2SK168 2SC535 2SC461 2SC1342 2SC2634 2SA733 2SC1675 2SD882 µPC1167 µPC1161C HA1151 LB1405 µPC574 LC7259 SP8629 1SV55 1SV68 1S2473 VD1212 S1VB RD13EB3 RD9.1EB1 RD5.6EB

• Main principle
• Superhet with RF-stage; ZF/IF 455/10700 kHz

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Sintonizador Estereofónico S-4001 [5 teclas preselectoras] - Thomson Española S.A.; Thomson

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 300 x 63 x 230 mm / 11.8 x 2.5 x 9.1 inch

• Notes

• Thomson Española S.A. Sintonizador Estereofónico S-4001 con 5 presintonías

  Véase:

  • Thomson Española, S.A. S-4001 con seis presintonías

  Listado un único semiconductor por tipo

• Net weight (2.2 lb = 1 kg)
• 2.8 kg / 6 lb 2.7 oz (6.167 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
